TRIJICON® SNIPE-IR™ Thermal Clip-On System
PLEASE INQUIRE FOR STOCK STATUS BEFORE PLACING YOUR ORDER
The Trijicon® SNIPE-IR™ is designed to become one with your optical day sight, both on the battlefield and on the hunting field. The thermal scope's NO-SHOT ZERO feature makes it simple to verify boresight when attached.
Meet the perfect clip-on thermal sight. Small and lightweight, the SNIPE-IR is designed to fit comfortably in front of your optical day sight for 24-hour weapon sighting applications.
THUMBSTICK SYSTEM CONTROLLER
Our fully ruggedized, weatherproof, multidirectional thumbstick control comes standard. Unlike most conventional buttons, the SNIPE-IR controls are large and easy to find in complete darkness.
VISRELAY COLLIMATING OPTIC
The SNIPE-IR offers a VisRelay Collimating Optic that eliminates parallax, making it the ideal choice for a 24-hour weapon sighting system.
DIGITAL FOCUS CONTROL IMAGE ENHANCEMENT
Digital Focus Control (DFC) allows you to not only focus your picture to your optimum setting; it allows you to sharpen your overall picture for extreme detail.
NO-SHOT ZERO SIGHT-IN SEAMLESS INTEGRATION
The SNIPE-IR's NO-SHOT ZERO feature makes it simple to verify boresight when attached. And it offers easy sight-in integration for accurate calibrations with the 4x32 ACOG®and 3x and 4x day optics, as well as a large range of variable rifle sights.
MAXPOL POLARITY WHITE HOT/BLACK HOT
The SNIPE-IR™ comes with an easy-to-control polarity mode that lets you switch between three levels of white hot and three levels of black hot. Why limit yourself to one setting? With low, medium and high levels, you can pick your perfect mode.
SPECIFICATIONS
| SENSOR TYPE | Uncooled VOx (Vanadium Oxide) |
| THERMAL SENSITIVITY | <50mk |
| SENSOR RESOLUTION | 640x480 |
| SENSOR PITCH | 12 Micron |
| FRAME RATE | 60 Hz with a 30 Hz Power Save Mode |
| SPECTRAL RESPONSE | 8 - 12 Microns |
| DISPLAY TYPE | Digital OLED |
| FIELD OF VIEW | 12° Horizontal |
| SYSTEM MODES | CLIP-ON / HYBRID / DEDICATED |
| DISPLAY RESOLUTION | 640x480 pixels |
| BASIC FEATURES | E-Zoom, Polarity |
| ADVANCED FEATURES |
NO-SHOT ZERO Image Capture DFC – Digital Focus Control |
| START-UP TIME | Approx. 5 Seconds |
| VIDEO OUTPUT | Analog RS-170 (with Optional Cable) |
| BATTERY TYPE | 2 x CR123 |
| BATTERY LIFE | 3.5 Hours @ 60 Hz |
| WEAPON MOUNT | Mini D–LOC Mount – Standard Model |
| DAY SIGHT COMPATIBILITY |
1x up to 4x Fixed Sights 1-4x and 1-6x Variable Sights 2.5-10x up to 4-12x Variable Sights |
| WEIGHT | 24.6 oz (700 grams) |
| DIMENSIONS | 7.4" L x 3.0" H x 2.95" W |
| EXIT PUPIL | 30mm clip-on |
| DIOPTER | -6 / +2 |
| ENVIRONMENTAL | -40c to +55c Operating -45c to +75c Storage |
