Autel EVO II Dual 640T V3 (Rugged Kit)
The Autel Robotics EVO II Dual 640T V3 radiometric thermal drone expands on the existing EVO line with more features and better performance, but at a more affordable price point. It features a high resolution 13mm, 640 x 512, 12μm thermal camera with radiometric temperature measurement, as well as an ultra-sensitive 0.8” / 50MP visible camera. Both sensors are housed in a compact gimbal system and all functions are controlled with the included smart controller.
The EVO II Dual 640T V3 can be used for a variety of missions to include powerline inspection, firefighting, law enforcement, search and rescue, chemical plant inspection, and solar panel inspection. It is also the ideal tool for tracking and locating feral pigs or performing wildlife surveys.
The thermal and visible cameras both incorporate digital zoom and the user can adjust many parameters. It also features a unique “Picture-in-Picture” mode, where the operator can have a thermal overlay of the visible camera’s view. This is extremely useful for first responders or search and rescue personnel. A new image processing algorithm allows greater detail in thermal imaging. Other notable features include central, spot, and regional temperature measurement, temperature alarm with isotherm and image enhancement, and 10 thermal color pallets.
The 50MP / 0.8” ultra-sensitive visible camera features the Moonlight Algorithm 2.0, which provides greater noise reduction in low light conditions. The 0.8” sensor size is up to 233% more surface area than competitors ½” sensors for maximum detail in high-contrast lighting. RYYB sensor technology moves away from traditional RGB cameras by offering up to 40% more light sensitivity in low light conditions. Fast and accurate focusing is provided by Phase Detection Autofocus and Contrast Detection Autofocus technology. This camera supports up to 4x lossless zoom, and up to 16x total digital zoom. 4K HDR technology automatically balances over and under exposure to produce clearer images with more layers.
The included Autel V3 Smart Controller features a large 7.9”, 2000 NIT high-resolution, high-brightness display and can be viewed clearly in direct sunlight. Integrated Skylink 2.0 transmission technology allows for long distance operations of up to 9 miles and enhances anti-interference abilities with triple-band frequency hopping. The customized Android operating system allows for additional flexibility in allowing 3rd Apps. An IP43 water resistance rating ensures all weather performance. The EVO II Dual 640T V3 is also compatible with the Autel Live Deck 2 system to allow this drone to broadcast imaging to a wide variety of devices in real-time.
The EVO II Dual 640T V3 also has performance in mind with up to 38 minutes of continuous flight time, up to 45 MPH flight speed, and ability to operate in winds up to 27 MPH. Additionally, it can be rapidly deployed from the case to the air in under one minute. This unit allows the operator greater freedom than competitors by not having any flight zone restrictions and no forced updates that would prevent the pilot from taking off. 360 degree obstacle avoidance is provided by a group of 19 sensors including 12 visual cameras, the main camera, ultrasound, IMU’s and other sensors.
The Autel EVO II Dual 640T V3 Rugged Package is a true “Turn-Key” thermal drone package and includes the EVO II Dual 640T V3 Aircraft, V3 Smart Controller, three intelligent flight batteries, multi-battery charger, charger cables, car charger, spare propellors, spare controller sticks, and a 32GB SD card all housed in a waterproof carry case.
- 640 x 512, 12μm, 25Hz Thermal Camera
- 13mm Thermal Camera Lens
- Multiple Color Pallets
- 1-16X Digital Zoom (Thermal Camera)
- User Adjustable Parameters
- 0.8” / 50MP Visible Camera
- 16X Digital Zoom with 4X Lossless (Visible Camera)
- Autel V3 Smart Controller Included
- Skylink 2.0 Image / Data Transmission
- Live Deck 2.0 Compatibility
- 38 Minute Flight Time
- 9 Mile Transmission Range
- 45 MPH Maximum Flight Speed
- 27 MPH Wind Resistance
- 360 Degree Obstacle Avoidance
- 128GB Internal Storage
- MP4 / MOV / JPG File Formats
- No Forced Updates
- No “No-Fly” Zone Restrictions
- 1 Year Factory Warranty
- Autel EVO II Dual 640T V3 Thermal Drone
- Autel V3 Smart Controller
- Intelligent Flight Battery x 3
- Charging Cables
- Car Charger
- Spare Propellors
- Spare Controller Sticks
- 32GB SD Card
- Waterproof Carry Case
